篦式冷却机 Grate Cooler
篦式冷却机是一种骤冷式冷却机，篦式冷却机原理是：用鼓风机吹冷风，将铺在篦板上成层状的孰料加以骤冷，使孰料温度由1200℃骤降至100℃以下，冷却的大量废气除入窑作二次风，还可以入煤磨作烘干热源用。
Grate cooler is a cooler cooling down suddenly. Its working principle is: blow cool air with blower and cool down the stratified clinker on the grate, so that the clinker temperature drops from 1200℃ to lower than 100℃, the large quantity of cooled waster gas enters into the kiln as secondary air. It can also enter into the coal mill as drying heat source.
技术参数
| 规格型号 | 入料温度 | 出料温度 | 冲程次数 | 产量 | 配套设备 | 设备质量 | |
| 破碎机型号规格 | 拉链机型号规格 | ||||||
| ℃ | ℃ | r/min | t/d | t | |||
| 500T/D | 1350 | 60＋环境 | 5~15 | 500 | ф900×1690 | 250×1250 | 81.5 |
| 800T/D | 1350 | 60＋环境 | 5~15 | 800 | ф1200×2150 | 250×15500 | 128 |
| 1000T/D | 1350 | 60＋环境 | 5~15 | 1000 | ф1200×2150 | 250×15500 | 130 |
| 1500T/D | 1371 | 60＋环境 | 3~11 | 1500 | ф1000×2700 | 250×19660 | 145 |
| 2500T/D | 1371 | 60＋环境 | 2~12 | 2500 | ф1000×3000 | 250×26260 | 178.9 |
| 2800T/D | 1371 | 60＋环境 | 2~12 | 2800 | ф1000×3000 | 250×26260 | 192 |
| 5500T/D | 1371 | 60＋环境 | 5~25 | 5500 | ф1000×3300 | 400×37000 | 309 |
