·GZ型电磁振动给料机 Elector-magnetic vibrating feede

振动给料机

GZ型电磁振动给料机 Elector-magnetic vibrating feeder

GZ系列电磁振动给料机广泛应用于矿山、冶金、煤炭、建材、轻工、化工、电力、机械、粮食等各个行业，把块状、颗粒状及粉状物料从储料仓或漏半中均匀连续或定量地给到受料装置中。例如，向带式输送机、半式提升机、筛分设备等给料，向破碎机、粉碎机等喂料，以及用于自动配料、定量包装等，并可用于自动控制的流程中，实现生产流程的自动化。

GZ elector-magnetic vibrating feeders are widely used in different industries such as mining, metallurgy, coal, building material, light industry, chemical, power, machinery and grain. They convey a given amount of block material, granule material and powdery material from the storage silo or hopper to the material receiving device in an even and uninterrupted way. For example, they feed materials through belt conveyors, bucket elevators or screening equipment to crushers or grinders. Besides, they are used for automatic charging, quantitative packaging, etc and even in the processes of automatic control to realize automation of production flow.

型号规格 Model	槽子规格			给矿粒度 Feed size	双振幅	供电电压	功率 Power	给料量 t/h		外形尺寸 Dimension	重量 Weight
	长	宽	高	给矿粒度 Feed size	双振幅	供电电压	功率 Power	水平	-10°	外形尺寸 Dimension	重量 Weight
	mm	mm	mm	mm	mm	V	kw			mm	t
GZ₁	600	200	100	50	1.75	220	0.06	5	7	910×376×485	0.07
GZ₂	800	300	120	50	1.75	220	0.15	10	14	1175×506×600	0.15
GZ₃	900	400	150	75	1.75	220	0.2	25	35	1325×574×675	0.22
GZ₄	1100	500	200	100	1.75	220	0.45	50	70	1615×762×814	0.41
GZ₅	1200	700	250	150	1.75	220	0.65	100	140	1815×840×980	0.66
GZ₆	1600	900	250	200	1.5	380	1.5	150	210	2410×1092×1530	1.25
GZ₇	1800	1100	250	250	1.5	380	3.0	250	350	2800×1332×1710	1.9
GZ₈	2200	1300	300	300	1.5	380	4.0	400	560	3302×1556×1995	3.15
GZ₉	2400	1500	300	350	1.5	380	5.5	600	840	3515×1776×2200	3.75
GZ₁₀	2500	1800	375	500	1.5	380	4×2	750	1050	3630×2500×2235	6.5
GZ₁₁	2800	2000	375	500	1.5	380	5.5×2	1000	1400	4060×2640×2310	7.7
